FD350 35 Ton Ultra Heavy Lift Forklift Truck With Turbocharged Weichai WD12 Engine

Above 30 tonnes the engineering stops being incremental. The FD350 uses a 25 mm side plate frame with a full box section behind the counterweight, a 4000 mm mast built from 220 mm wide channels with 16 mm flanges, and a turbocharged Weichai WD12 engine rated at 247 kW driving through a powershift transmission and a Kessler planetary axle with differential lock. Hydraulic flow comes from two pumps working in parallel, so lift speed on a 4000 mm stroke stays above 380 mm per
